Pipe Systems
Dynamic BluePE®
Compressed Air Pipe System
Axsa Corporation offer Dynamic BluePE®, an instantly recognisable and superior compressed air piping system. Dynamic BluePE® combines the numerous strengths of PE100 polyethylene with the flexibility and choice offered by 3 different connection/fitting methods, each offering unsurpassed ease of installation. We recommend which fitting would best suit your on-going requirements.
The design flexibility of Dynamic BluePE® compressed air systems coupled with quality componentry makes it a renowned product of Axsa Corporation. Offering the highest levels of safety, Dynamic BluePE® is preferred and specified by leading Mechanical Engineers for all Australian industry.
Dynamic BluePE® offers quick installation, strength, safety, reliability and long levity with no maintenance required.
Dynamic BluePE® Advantages
- Quick & Easy To Install
- Simple To Alter Or Adapt
- Lightweight
- Strong & Safe
- Low Frictional Losses
- No Rust
- Pipe Sizes 20mm To 160mm; Larger Sizes Available
- Food Grade
- Breathing Air Applications
- Distinctive Blue Colour
- Excellent Thermal Properties
- Suitable For Underground Underground Applications
- Underpressure Connection Fittings
- 50 Year Warranty
- Aesthetically Pleasing
- Fast And Efficient
Dynamic BluePE® can be installed 2-5 times faster than traditional materials and is clean & safe. No threading, flaring, gluing or Oxy/Act welding. Modifications and additional branches, etc are added with a minimum of disruption & cost.
Superior Safety
Dynamic BluePE® is a system of the highest integrity and has an integral Safety Factor of 2:1. Suitable for compressed air pressures up to 16 bar and fluids up to 25 bar as per Australia Standards AS4130, Dynamic BluePE® has higher strength, greater wall thickness, high pressure/ temperature capabilities with minimum 50 year design life. Extremely robust and impact resistant – is not brittle like PVC & PP, (PVC is not safe for compressed air). Excellent for under-ground applications. Thermally stable and suitable for continuous operation within the temperature range of -20deg C to +60deg C, Dynamic BluePE® can withstand short term rises up to 95deg C.
Corrosion Free
Dynamic BluePE® is corrosion free! Air quality and flow rates are not compromised by age. Traditional galvanised iron air pipe corrodes causing contamination of air supply damaging tools & pneumatics, increased friction resulting in energy losses, reduced bore and eventual need for replacement.
Food Grade & Breathing Air
Dynamic BluePE® is approved for food plants as it does not support bacterial growth or micro-organisms and complies with AS2070.1 "Plastic material for food contact use". Compression fittings conform to AS4129, BS6920, threaded fittings to AS3855.3 Dynamic BluePE® is also suitable for breathing air systems.
Chemical Resistance
Dynamic BluePE® has extensive chemical resistance/compatibility and provides a solution for corrosive environments. The three fitting ranges available offer various solutions; Compression Fittings come standard with Nitrile 0 rings and Acetal grip-rings, for some chemical applications Viton and EPDM 0 rings and CPVC grip-rings can be used. Dynamic BluePE® Socket Fusion provides for a continuous use of identical pipe & fitting material. Please refer to Technical Department for specific applications.
Engineering Design Flexibility
Dynamic BluePE® provides engineers & designers maximum flexibility with Socket Fusion, Electro Fusion & Compression fitting ranges. This system assists Australian Industry by a total package which is readily altered and changed with minimal "shutdown" time and is ideally suited to today's requirement for quick installation.
Dynamic BluePECost Savings
- Economical purchase
- Quick installation, Long levity with no maintenance required
- Elimination of costly air leaks
- Energy savings through reduced friction
- Ultra smooth bore and no rust/scale build-up
- Savings in modifcations, additional branches can be connected while system under pressure
